Aire & Calder Navigation: Goole to tail of Leeds Lock
Castleford Lock is limiting due to the curve of the lock chamber. Heck Road Bridge is now lower than Stubbs Bridge (investigations underway), which was previously limiting. A height of 3.6m (11ft 9") at Heck should be seen as maximum at the crown during normal water. | L 61m / 200ft
B 6.1m / 20ft
D 2.5m / 8ft 2"
H 3.81m / 12ft 6" | Fits |
|---|
Aire & Calder Navigation: Tail of Leeds Lock to Tail of River Lock
Note 1: Pleasure craft dimensions showing small lock being limiting unless by previous arrangement to access full lock. Note 2: Headroom at Crown Point Bridge at summer levels. | L 19.8m / 64ft 11"
B 5.4m / 17ft 8"
D 2.4m / 7ft 6"
H 3.6m / 11ft 9" | Fits |
|---|
Aire & Calder Navigation: Wakefield Branch
Note 1: Broadreach Lock: Pleasure craft dimensions showing small lock being limiting unless by prior arrangement to access full lock giving an extra 43m. Note 2: Heck Road Bridge: Still limiting due to constraints on other sections leading to the Wakefield Branch. A height of 3.6m at Heck should be seen as maximum at the crown during normal water level. | L 21.4m / 70ft 2"
B 5.4m / 17ft 8"
D 2.3m / 7ft 6"
H 3.66m / 12ft | Fits |
|---|
| Aire & Calder Navigation: River Aire | L 23.92m / 78ft 6"
B 5.03m / 16ft 6"
D 1.52m / 5ft
H 2.9m / 9ft 6" | Fits |
|---|
Selby Canal
Note: Burton Hall Bridge is the limiting dimension. | L 23.92m / 78ft 6"
B 5.03m / 16ft 6"
D 1.52m / 5ft
H 2.9m / 9ft 6" | Fits |
|---|
| Selby Canal: From River Ouse into Selby Basin only | L 23.92m / 78ft 6"
B 5.69m / 18ft. 8"
D Max 2.13m / 7ft depending on tide
H not given | Fits |
|---|
| Ashby Canal (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.07m / 3ft 6"
H 1.98m / 6ft 6" | Fits |
|---|
| Ashton Canal (narrow) | L 21.79m / 71ft 5"
B 2.13m / 7ft
D 0.9m / 3ft
H 1.82m / 5ft 11" | Fits |
|---|
Birmingham Canal Navigations (narrow)
Note: Headroom through Dudley Tunnel is considerably restricted, contact local office for further information. | L 21.79m / 71ft 6"
B 2.13m / 7ft
D 0.94m / 3ft 1"
H 1.98m / 6ft 6" | Fits |
|---|
| Birmingham & Fazeley Canal (narrow) | L 21.79m / 71ft 6"
B 2.13m / 7ft
D 0.94m / 3ft 1"
H 1.98m / 6ft 6" | Fits |
|---|
Bridgwater & Taunton Canal
Note: Locks are 4.42m (14ft 6") wide; beam is restricted by bridges. | L 15.24m / 50ft
B 3.2m / 10ft 6"
D 0.9m / 2ft 11"
H 2.1m / 6ft 10" | Too big: length over by 2.44 m |
|---|
| Calder & Hebble Navigation | L 17.53m / 57ft 6"
B 4.32m / 14ft 2"
D 1.07m / 3ft 6"
H 2.97m / 9ft 9" | Too big: length over by 0.15 m |
|---|
| Caldon Canal (narrow): Etruria Junction to Hazlehurst Junction | L 21.95m / 72ft
B 2.13m / 7ft
D 1.2m / 3ft 11"
H 1.78m / 5ft 10" | Fits |
|---|
| Caldon Canal (narrow): Hazlehurst Junction to Leek | L 21.95m / 72ft
B 2.13m / 7ft
D 1.2m / 3ft 11"
H 2.05m / 6ft 9" | Fits |
|---|
Caldon Canal (narrow): Hazlehurst Junction to Froghall Tunnel
Note: Headroom through Froghall Tunnel considerably restricted to 2.03m (6ft 8") beam and 1.52m (5ft) headroom. Pinch point: Less than 2.13m (7ft) at Consal Forge Railway Bridge (landslip). Tunnel: 2.13m (7ft) beam is acceptable, the issue is tumblehome and height. | L 21.95m / 72ft
B 2.13m / 7ft
D 1.2m / 3ft 11"
H 2.05m / 6ft 9" | Fits |
|---|
Chesterfield Canal: River Trent into West Stockwith Basin only
Note: Whitsunday Pie Lock walls taper towards the lock floor and you need to take this into account when navigating this canal. Measurements within stoppages are being taken this winter to determine the dimensions of known pinch points. | L 21.95m / 72ft
B 5.33m / 17ft 6"
D 2.44m / 8ft
H Unlimited | Fits |
|---|
Chesterfield Canal: West Stockwith Basin to tail Morse Lock (narrow)
Note: Locks up to Redford are 4.57m (15ft) wide but navigation for broad bean craft is restricted due to the width 2.59m (8ft 6") at Manor Farm Bridge, Walkeringham. | L 21.95m / 72ft
B 2.13m / 7ft
D 0.98m / 3ft 2"
H 2.15m / 7ft 1" | Fits |
|---|
Chesterfield Canal: Tail of Morse Lock to Shireoaks (narrow)
Note: Some locks are only just 2.13m (7ft) wide and passage for some craft up to 2.13m (7ft) beam may be possible. | L 21.95m / 72ft
B 2.08m / 6ft 10"
D 0.98m / 3ft 2"
H 2.15m / 7ft 1" | Fits |
|---|
| Coventry Canal (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.07m / 3ft 6"
H 2.08m / 6ft 10" | Fits |
|---|
| Droitwich Canal: Hawford Junction to Bridge 15 | L 18.59m / 61ft
B 4.20m / 13ft 09"
D not given
H not given | Fits |
|---|
| Droitwich Canal: Hawford Junction to Bridge 15 (narrow) | L 21.80m / 71ft 6"
B 2.13m / 7ft
D not given
H not given | Fits |
|---|
| Droitwich Canal: Bridge 15 to Barge Lock (narrow) | L 21.80m / 71ft 6"
B 2.13m / 7ft
D not given
H not given | Fits |
|---|
| Droitwich Canal: River Salwarpe Barge Lock to Junction Lock 7 (narrow) | L 21.80m / 71ft 6"
B 2.13m / 7ft
D not given
H not given | Fits |
|---|
Droitwich Canal: Droitwich Junction Canal River Salwarpe to Hanbury Junction Lock 7 (narrow)
*Narrow beam boats will fit up to the longer length shown. Pinch points: M5 and the top lock. | L 21.80m / 71ft 6"
B 2.13m / 7ft
D not given
H not given | Fits |
|---|
Erewash Canal
Note 1: Beam is limited by low arched bridges; wider beam up to about 13ft may be possible depending on the headroom needed. Note 2: Locks are more than 4.27m (14ft) wide and will therefore take two narrowboats. | L 21.95m / 72ft
B 3.2m / 10ft 6"
D 0.91m / 3ft
H 2.03m / 6ft 8" | Fits |
|---|
| Fossdyke Navigation | L 21.3m / 70ft
B 4.67m / 15ft 4"
D 1.52m / 4ft 11"
H 3.66m / 12ft | Fits |
|---|
| Gloucester & Sharpness Canal: River Severn into Sharpness Docks only | L 91.44m / 300ft
B 16.75m / 55ft
D not given
H not given | Fits |
|---|
Gloucester & Sharpness Canal: Sharpness Docks to Gloucester Docks
Note: Parkend Bridge/Fretherne at 3.5m (11ft 6") draught. The main constraint is the approach to each bridge at a specified depth. Harbour master to advise. Note 2: 64m (201ft) limitation due to bends in canal. See advice from harbour master for longer vessels. | L 64m / 210ft
B 9.6m / 31ft 5"
D 3.5m / 11ft 6"
H 32m / 105ft | Fits |
|---|
| Gloucester & Sharpness Canal: Gloucester Docks to River Severn through Gloucester Lock | L 41.15m / 135ft
B 6.4m / 21ft
D 1.83m / 6ft
H 7.5m / 24ft 7" | Fits |
|---|
| Grand Union Canal: River Thames into Limehouse Basin only | L 28m / 91ft 10"
B 7.5m / 24ft 7"
D not given
H not given | Fits |
|---|
Grand Union Canal: River Thames into Brentford Basin only
Note: Duplicated locks; one lock is larger than the other. | L 22.87m / 75ft
B 5.02m / 16ft 5"
D not given
H not given | Fits |
|---|
| Regents Canal | L 21.95m / 72ft
B 4.34m / 14ft 3"
D 1.17m / 3ft 10"
H 2.67m / 8ft 9" | Fits |
|---|
| Paddington Arm (Grand Union Canal): Bulls Bridge to Little Venice (no locks) | L not given
B 4.3m / 14ft 1"
D 1.3m / 4ft 3"
H 2.67m / 8ft 9" | Not sure: the Trust gives no length |
|---|
| Grand Union Canal (Main Line): Brentford to Bulls Bridge | L 21.95m / 72ft
B 4.27m / 14ft
D 1.3m / 4ft 3"
H 2.67m / 8ft 9" | Fits |
|---|
| Grand Union Canal (Main Line): Bulls Bridge to Berkhamsted | L 21.95m / 72ft
B 4.27m / 14ft
D 1.1m / 3ft 7"
H 2.67m / 8ft 9" | Fits |
|---|
Grand Union Canal (Main Line): Berkhamsted to Long Buckby
Pinch point: 14ft Lock S. Leighton Buzzard. | L 21.95m / 72ft
B 3.81m / 12ft 6"
D 1.17m / 3ft 10"
H 2.67m / 8 ft 9" | Fits |
|---|
Grand Union Canal (Main Line): Long Buckby to Camp Hill Locks
NOTE: Bridge 24 Warwickshire Fly Boats, Long Itchington, between Bridge 22, Bridleway and Bridge 60, Blue Bridge the maximum beam for navigation is reduced to 12’. Upstream winding hole: Kingswood Junction Downstream winding hole: Napton Junction Further information available on our notices and stoppage page. | L 21.95m / 72ft
B 3.81m / 12ft 6"
D 1.17m / 3ft 10"
H 1.9m / 6ft 3" | Fits |
|---|
Grand Union Canal (Main Line): Camp Hill Locks to Digbeth and Salford
Pinch point: top of Camp Hill. | L 21.69m / 71ft 2"
B 2.13m / 7ft
D 1.17m / 3ft 10"
H 2.44m / 8ft | Fits |
|---|
Slough Arm (no locks)
Note: adjoining waterways: max length: 21.95m (72ft), max beam: 4.27m (14ft). | L not given
B 4.92m / 16ft 2"
D 1.1m / 3ft 7"
H 2.33m / 7ft 7" | Not sure: the Trust gives no length |
|---|
| Wendover Arm (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D not given
H not given | Fits |
|---|
| Aylesbury Arm (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 2.28m / 7ft 6" | Fits |
|---|
| Northampton Arm (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 2.18m / 7ft 1" | Fits |
|---|
| Leicester Line (Grand Union Canal): Norton Junction to Foxton (narrow) | L 21.79m / 71ft 6"
B 2.12m / 6ft 11"
D 1m / 3ft 3"
H 2.28m / 7ft 6" | Fits |
|---|
| Leicester Line (Grand Union Canal): Foxton to Kings Lock | L 21.95m / 72ft
B 3.05m / 10ft
D 1m . 3ft 3"
H 2.23m / 7ft | Fits |
|---|
| Leicester Line (Grand Union Canal): Kings Lock to Leicester | L 24.1m / 79ft
B 3.05m / 10ft
D 1m / 3ft 3"
H 2.13m / 7ft | Fits |
|---|
| Welford Arm (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1m / 3ft 3"
H 2.13m / 7ft | Fits |
|---|
| Market Harborough Arm | L 21.79m / 71ft 6"
B 2.9m / 9ft 6"
D 0.84m / 2ft 9"
H 2.06m / 6ft 9" | Fits |
|---|
| Hertford Union Canal | L 21.95m / 72ft
B 4.45m / 14 ft 7"
D 1.3m / 4ft 3"
H 2.44m / 8ft | Fits |
|---|
| Huddersfield Broad Canal | L 17.52m / 57ft 6"
B 4.32m / 14ft 2"
D 1.3m / 4ft 3"
H 2.97m / 9ft 9" | Too big: length over by 0.16 m |
|---|
Huddersfield Narrow Canal (narrow): Standedge Tunnel to Portland Basin
Note: 7ft beam up to Lock 21W. | L 21.35m / 70ft
B 2.08m / 6ft 10"
D 1.05m / 3ft 5"
H 1.88m / 6ft 2" | Fits |
|---|
Huddersfield Narrow Canal (narrow): Aspley Basin to Standedge Tunnel (narrow)
Note: The height restriction tallies with that of Standedge Tunnel, and the restriction applies before HNC at Lock 1. | L 21.95m / 72ft
B 2.08m / 6ft 10"
D 0.75m / 2ft 5"
H 1.88m / 6ft 2" | Fits |
|---|
| Kennet & Avon Canal: Hanham Lock to Bridge 194 (Bath) | L 22.55m / 74ft
B 4.88m / 16ft
D 1.3m / 4ft 3"
H 2.67m / 8ft 10" | Fits |
|---|
| Kennet & Avon Canal: Bridge 194 - Blakes Lock (Reading) | L 21.95m / 72ft
B 4m / 13ft 1"
D 1.1m /3ft 7"
H 2.4m / 7ft 10" | Fits |
|---|
Lancaster Canal including Glasson Branch: Main Line
Height at Ashton Basin 2m (6ft 7"). No navigable locks on the Lancaster, just the Ribble Link and Glasson Branch. | L 21.95m / 72ft
B 4.65m / 15ft 3"
D 0.99, / 3ft 3"
H 2.49m / 8ft 2" | Fits |
|---|
| Lee Navigation: Below Old Ford Locks (entering from Limehouse) | L 25.91m / 85ft
B 5.79m / 19ft
D 1.76m / 5ft 9"
H 2.13m / 7ft | Fits |
|---|
| Lee Navigation: Below Old Ford Locks (entering from Bow) | L 29.8m / 97ft 9"
B 5.88 m / 19ft 3"
D 1.3m / 4ft 2"
H 2.6m / 8ft 6" | Fits |
|---|
| Lee Navigation: Old Ford Locks to Ponders End | L 25.91m / 85ft
B 5.5m / 18ft
D 1.52m / 5ft
H 2.13m / 7ft | Fits |
|---|
| Lee Navigation: Ponders End to Hertford | L 22.86m / 75ft
B 4.72m / 15ft 6"
D 1.3m / 4ft 3"
H 2.11m / 6ft 11" | Fits |
|---|
Leeds & Liverpool Canal
Note: Limiting height in Foulridge Tunnel | L 19.51m / 64ft
B 4.34m / 14ft 3"
D 1.22m / 4ft
H 2.67m / 8ft 9" | Fits |
|---|
| Leigh Branch | L 21.95m / 72ft
B 4.34m / 14ft 3"
D 1.2m / 3ft 11"
H 2.3m / 7ft 6" | Fits |
|---|
| Rufford Branch | L 18.89m / 62ft
B 4.34m / 14ft 3"
D 1.1m / 3ft 7"
H 2.51m / 8ft 3" | Fits |
|---|
Llangollen Canal (narrow): Hurleston to Pontcysyllte
Pinch point: Hurleston | L 21.95m / 72ft
B 2.11m / 6ft 11"
D 0.76m / 2ft 6"
H 2.12m / 7ft | Fits |
|---|
| Llangollen Canal (narrow): Pontcysyllte to Llangollen | L 21.95m / 72ft
B 2.11m / 6ft 11"
D 0.75m / 2ft 5"
H 2.13m / 7ft | Fits |
|---|
| Macclesfield Canal (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.07m / 3ft 6"
H 2.08m / 6ft 10" | Fits |
|---|
Monmouthshire & Brecon Canal
Note: Ashford Tunnel limits cabin profile, e.g. 1.7m (5ft 7") height at 2.1m (6ft 10") width. Contact local office for further detail. | L 16.76m / 55ft
B 2.59m / 8ft 5"
D 0.75m / 2ft 6"
H 1.8m / 5ft 9" | Too big: length over by 0.92 m |
|---|
| Montgomery Canal (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.2m / 3ft 11"
H 1.83m / 6ft | Fits |
|---|
River Ouse (Yorkshire)
Note: Depths are in all cases dependants on river/tidal conditions. | L 17.5m / 57ft 4"
B 4.66m / 15ft 2"
D Tidal
H 5.94m / 19ft 5" Naburn Bridge | Too big: length over by 0.18 m |
|---|
| River Ouse (Yorkshire): Naburn Locks to York | L 42.62m / 140ft
B 7.31m / 24ft
D not given
H not given | Fits |
|---|
| River Ouse (Yorkshire): York to Swale NAB | L 18.28m / 59ft 11"
B 4.67m / 15ft 4"
D not given
H not given | Fits |
|---|
| Oxford Canal (narrow): Braunston Junction to Wigrams (Napton Junction) (Narrow) | L 21.96m / 72ft
B 2.13m / 7ft
D 1.17m / 3ft 10"
H 2.44m / 8ft | Fits |
|---|
Oxford Canal (narrow): Wigrams (Napton Junction) to Oxford (narrow)
Pinch point: second lock up. | L 21.96m / 72ft
B 2.13m / 7ft
D 1.23m / 4ft
H 1.98m / 6ft 6" | Fits |
|---|
| Oxford Canal (narrow): Braunston Junction to Hawkesbury Junction (Sutton Stop) (narrow) | L 21.96m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 2.07m / 6ft 9" | Fits |
|---|
| Peak Forest Canal (narrow) | L 21.96m / 72ft
B 2.13m / 7ft
D 1.07m / 3ft 6"
H 1.83m / 6ft | Fits |
|---|
| Pocklington Canal | L 17.37m / 56ft 11"
B 4.3m / 14ft 1"
D 1.22m / 4ft
H 2.34m /7ft 8" | Too big: length over by 0.31 m |
|---|
Pocklington Canal: Ribble Millenium Link
Note: Boat size is recommended from channel widths rather than lock sizes, confirm with us before passage - Locks 7, 8, and 9 are tidal. The locks on the Ribble Link are for crafts 21.94m (72ft) although the Rufford Branch is 18.9m (62ft). | L 18.8m / 62ft
B 3.2m / 10ft 6"
D 0.7m / 2ft 3"
H 2.43m / 8ft | Fits |
|---|
| Ripon Canal | L 17.37m / 56ft 11"
B 4.3m / 14ft 1"
D 1.01m / 3ft 4"
H 2.59m / 8ft 6" | Too big: length over by 0.31 m |
|---|
Rochdale Canal
Pinch point: Rodwell Tower 4.14m (13ft 6"). | L 21.95m / 72ft
B 2.91m / 9ft 5"
D 1.19m / 3ft 9"
H 1.83m / 6ft | Fits |
|---|
| River Severn: Gloucester to Worcester | L 42.67m / 140ft
B 6.65m / 15ft 6"
D 2.51m / 8ft 3"
H 7.47m / 24ft 6" | Fits |
|---|
River Severn: Worcester to Stourport
Note: Draught and headroom measured at low summer levels. | L 27.43m / 90ft
B 5.79m / 19ft
D 1.83m / 6ft
H 6.1m / 20ft | Fits |
|---|
| Sheffield & South Yorkshire Navigation: Tinsley to Rotherham | L 18.75m / 61ft 6"
B 4.65m / 15ft 3"
D 1.37m / 4ft 5"
H 3.05m / 10ft | Fits |
|---|
| Sheffield & South Yorkshire Navigation: Rotherham to Bramwith inc New Junction Canal | L 59.44m / 195ft
B 5.36m / 17ft 7"
D 3.05m / 10ft
H 3.3m / 10ft 10" | Fits |
|---|
Sheffield & Tinsley
Note: The cill and channel depth from Tinsley Bottom Lock to Sheffield Basin has a maximum draught of 1.22m (4ft). | L 18.75m / 61ft 6"
B 4.72m / 15ft 6"
D 2.13m / 7ft
H 2.8m / 9ft 2" | Fits |
|---|
Stainforth & Keadby Canal
Note: Through passage is limited by Thorne Lock. For the Bramwith to Thorne section, dimensions are as for the main line to Rotherham. Passage from River Trent to Thorne is limited by Keadby Lock 23.67m x 6.86m (77ft 7" x 22ft 6") although longer craft can travel when the tide makes a level. Two narrowboats up to about 18.79m (61ft 8") can pass through Thorne Lock diagonally. | L 18.8m / 61ft 8"
B 5.2m / 17ft 1"
D 2.22m / 7ft 3"
H 3.3m / 10ft 10" | Fits |
|---|
Shropshire Union Canal: Ellesmere Port to tail of Northgate Locks (Chester)
Pinch point: Motorway bridge 2.95m (9ft 8"); Ellesmere Port and the Railway Bridge below Bunbury at 22.43m (73ft 6"). | L 21.95m / 72ft
B 2.95m / 9ft 8"
D 1.1m / 3ft 7"
H 2.44m / 8ft | Fits |
|---|
| Shropshire Union Canal: Tail of Northgate locks to top of Bunbury Locks | L 21.95m / 72ft
B 2.95m / 9ft 8"
D 1.1m / 3ft 7"
H 2.44m / 8ft | Fits |
|---|
| Shropshire Union Canal: Bunbury to Nantwich | L 21.95m / 72ft
B 2.95m / 9ft 8"
D 1.14m / 3ft 9"
H 2.44m / 8ft | Fits |
|---|
| Shropshire Union Canal: Nantwich to Autherley Junction (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.14m / 3ft 9"
H 2.44m / 8ft | Fits |
|---|
| Shropshire Union Canal: River Dee Branch | L 21.95m / 72ft
B 4.3m / 14ft 1"
D 1.37m / 4ft 6"
H 2.34m / 7ft 8" | Fits |
|---|
| Middlewich Branch (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.14m / 3ft 9"
H 2.34m / 7ft 8" | Fits |
|---|
| River Soar: From the junction with the River Trent to Leicester | L 21.34m / 70ft
B 4.37m / 14ft 4"
D 1.14m / 3ft 9"
H 2.13m / 7ft | Fits |
|---|
| Staffordshire & Worcestershire Canal (narrow): Stourport to Great Haywood | L 21.95m / 72ft
B 2.13m / 7ft
D 0.99m / 3ft 3"
H 1.82m / 6ft | Fits |
|---|
River Stort
Pinch point: Brick Lock | L 26.8m / 88ft
B 4.08m / 13ft 4"
D 1.1m / 3ft 7"
H 2.11m / 6ft 11" | Fits |
|---|
| Stourbridge Canal (inc. Stourbridge Town Arm) (narrow) | L 21.34m / 70ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 1.83m / 6ft | Fits |
|---|
Stratford-Upon-Avon Canal: River Avon into Stratford Basin
Note: Height restrictions at bridge coming off river. | L 21.95m / 72ft
B 4.57m / 25ft
D not given
H not given | Fits |
|---|
Stratford-Upon-Avon Canal: Lapworth Basin to Bancroft Basin (narrow)
Pinch point: Bridges 44 and 47. | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 1.83m / 6ft | Fits |
|---|
| Stratford-Upon-Avon Canal: Lapworth to Kings Norton (including Kingswood Branch) (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1m / 3ft 3"
H 2.1m / 6ft 11" | Fits |
|---|
| Tees Navigation | L 22m / 72ft 2"
B 6m / 19ft 8"
D 3.15m / 10ft 4"
H 5.5m / 18ft | Fits |
|---|
Trent Navigation (inc. Beeston Cut & Nottingham Canal): Shardlow to tail of Meadow Lane Lock, Nottingham
Note: Navigation includes Nottingham/Beeston Canal | L 21.34m / 70ft
B 4.27m / 14ft
D 1.07m / 3ft 6"
H 2.44m / 8ft | Fits |
|---|
Trent Navigation (inc. Beeston Cut & Nottingham Canal): Meadow Lane Lock to Cromwell Lock Tail (tidal)
Pinch point: Newark Town Bridge | L 42.67m / 140ft
B 5.72m / 18ft 9"
D 1.83m / 6ft
H 3.96m / 13ft | Fits |
|---|
| Trent Navigation (inc. Beeston Cut & Nottingham Canal): Tail of Cromwell Lock (tidal) to Gainsborough | L 45.57m / 149ft 6"
B 7.06m / 23ft 2"
D 2.13m / 7ft
H 4.27m / 14ft | Fits |
|---|
| Trent & Mersey Canal: Preston Brook to Croxton | L 21.95 / 72ft
B 2.74m / 9ft
D 1.1m / 3ft 7"
H 1.9m / 6ft 1" | Fits |
|---|
| Trent & Mersey Canal: Croxton to Wardle Junction (Middlewich Branch) (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 1.91m / 6ft 3" | Fits |
|---|
| Trent & Mersey Canal: Wardle Junction to Trentham Lock (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 1.78m / 5ft 10" | Fits |
|---|
| Trent & Mersey Canal: Trentham Lock to Great Haywood Junction (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 2.01m / 6ft 7" | Fits |
|---|
| Trent & Mersey Canal: Great Haywood Junction to Horninglow Basin, Burton-on-Trent (narrow) | L 21.95m / 72ft
B 2.13m / 7ft
D 1.1m / 3ft 7"
H 1.94m / 6ft 3" | Fits |
|---|
| Trent & Mersey Canal: Horninglow Basin to Shardlow | L 21.95m / 72ft
B 4.29m / 14ft 1"
D 1.1m / 3ft 7"
H 2.23m / 7ft 4" | Fits |
|---|
| Trent & Mersey Canal: Shardlow to Derwent Mouth Lock | L 21.95m / 72ft
B 4.26m / 13ft 11"
D 0.99m / 3ft 3"
H 2.13m / 7ft | Fits |
|---|
| River Ure: From its junction with the Ripon Canal to Swale Nab | L 17.37m / 56ft 11"
B 4.34m / 14ft 3"
D 1.98m / 6ft 6"
H 3.05m / 10ft | Too big: length over by 0.31 m |
|---|
| Weaver Navigation: Weston Point Dock to Weston Marsh Lock | L 65m / 213ft 3"
B 11.5m / 37ft 9"
D 3.2m / 10ft 6"
H 18m / 59ft | Fits |
|---|
| Weaver Navigation: Weston Marsh Lock to Winnington | L 65m / 213ft 3"
B 11.5m / 37ft 9"
D 3.2m / 10ft 6"
H 18m / 59ft | Fits |
|---|
| Weaver Navigation: Winnington to Winsford | L 60m / 196ft 10"
B 10.7m / 35ft 1"
D 2.9m / 9ft 6"
H 9m / 29ft 6" | Fits |
|---|
River Witham Navigation: Lincoln to Stamp End Lock
Note: Glory Hole Bridge, Lincoln, is 4.64m wide | L 22.86m / 75ft
B 5.4m / 17ft 8"
D 1.52m / 5ft
H 2.74m / 9ft | Fits |
|---|
| River Witham Navigation: Stamp End Lock to Boston Grand Sluice | L 21.41m / 70ft 3"
B 5.3m / 17ft 4"
D 1.52m / 5ft
H 3.5m / 11ft 6" | Fits |
|---|
| Worcester & Birmingham Canal: River Severn into Diglis Basin only | L 21.95m / 72ft
B 5.61m / 18ft 5"
D 1.9m / 6ft 3"
H Unlimited | Fits |
|---|
Worcester & Birmingham Canal: Gas Street to Diglis (narrow)
Last Edited: 26 March 2026 | L 21.95m / 72ft
B 2.13m / 7ft
D 0.9m / 3ft
H 2.3m / 7ft 6" | Fits |
|---|
